Electronics EG Avance 32 - 4 cyl.

Product Description

EG AVANCE 32 ECU Controller – 4 Cylinders

Technical Specifications:

• Supported engine cylinders: 3 or 4

• Lambda sensor support: 1 sensor connection

• Equipped with petrol injection support function

• Controller software allows calibration via Bluetooth and WiFi interface

• Wireless communication with a computer or mobile device using the EG MOVI app

• Connector: 32 PIN

• Housing: Composite

• Warranty: 2 years

Application Description:

The innovative EG AVANCE 32 controller is based on a new, enhanced hardware platform operating under a real-time system. All commands are executed without buffer delays, with processing times measured in hundredths of a second.

The compact design of the ECU fits into a small case with a single 32-pin automotive-grade Molex connector. Configuration allows connection of one LAMBDA sensor and enables communication with the vehicle's OBD system, significantly simplifying system diagnostics.

The controller features a petrol injection support function during gas operation to protect the engine under high load conditions.

The ECU software supports Bluetooth and WiFi communication, allowing for wireless interaction with a PC or mobile device running the EG MOVI application.

The price refers to 1 piece of the product.
