Injection rail AC W031 BFC (distributor) - 2 cyl.

Product Description

AC W031 BFC Injector Rail with Distributor – 2 Cylinders

Injector Technical Specifications:

• Power range per cylinder: 32.6 – 57.8 HP

• Operating pressure: 0.95 ÷ 1.5 bar

• Maximum operating pressure: 4.5 bar

• Operating temperature: -20°C to +120°C

• Opening time at 1.2 bar: 2.3 ms

• Closing time at 1.2 bar: 1.3 ms

• Weight: 0.41 kg

• Coil resistance: 1.9 Ω

• Supply voltage: 12V

• Maximum flow rate at 1.2 bar: 145 l/min

Set Includes:

• 2x AC W031 BFC injectors

• 2x Injector calibration nozzles Ø 6 / 1.5

• 2x Intake manifold nozzles

• 1x Rail end plug

• 1x Distributor with MAP sensor inlet

• 1x Inlet fitting

• 3x Clips

Application Description:

The STAG AC W031 BFC injector is designed for use in LPG and CNG gas injection systems in all vehicle engine types, including turbocharged engines.

The AC W031 BFC injector delivers excellent performance, allows direct mounting near the intake manifold, and is fully compatible with other AC S.A. products.

A key advantage of this system is its modularity—individual injectors can be combined into any number of injection sections.

The listed price applies to 1 complete set.
