AC W031 BFC Injection Rail – 3 Cylinders (with Distributor)

Product description

AC W031 BFC Injection Rail – 3 Cylinders (with Distributor)

Injector Technical Data

• Injector output per cylinder: approx. 40.8 – 57.8 HP at 1.0–1.2 bar

• Operating pressure: 0.95 – 1.5 bar

• Maximum operating pressure: 4.5 bar

• Operating temperature: –20 °C to +120 °C

• Opening time at 1.2 bar: approx. 2.3 ms

• Closing time at 1.2 bar: approx. 1.3 ms

• Coil resistance: 1.9 Ω

• Supply voltage: 12 V

• Maximum flow at 1.2 bar: approx. 145 l/min
  (Data based on manufacturer specifications) (agsiedlik.pl)

Kit Includes:

• 3× AC W031 BFC injectors

• 3× Injector calibration nozzles Ø 6 / 1.5

• 3× Intake manifold nozzles

• 1× Gas distributor with MAP sensor port

• 1× Distributor plug

• 1× Gas inlet fitting

• 3× Retaining clips (agsiedlik.pl)

Application

The AC W031 BFC injector rail is designed for sequential LPG and CNG gas injection systems in all types of vehicle engines, including turbocharged units. It delivers excellent injection performance, allows direct installation near the intake manifold, and is fully compatible with other products from AC S.A. A key advantage is the modular design, which makes it possible to combine individual injectors into any number of injection sections. (ac.com.pl)

Price applies to 1 complete kit.
