Gas inlet, manifold nozzle – long type 11 cm, Ø 7 mm (4 cylinders)
+48 603 775 778
Product Description
Inlet, manifold nozzle – long type 11 cm, Ø 6 mm (4 cylinders)
Technical Data
-
Thread: M7
-
Nozzle material: brass
-
Tube material: PTFE (polytetrafluoroethylene)
-
Inner tube diameter: 3 mm
-
Outer tube diameter: 4 mm
-
Operating pressure (at 20°C): 9 bar
-
Burst pressure (at 20°C): 36 bar
-
Flammability: non-flammable (UL94V0)
-
Operating temperature: -240°C to +260°C
-
Mounting type: locking head
Application Description
The nozzle consists of a fitting screwed into the intake manifold and a tube made of a synthetic material resistant to high temperatures and petroleum-based substances.
It enables direct gas injection under the engine’s intake valve, minimizing gas dispersion in the plenum manifold.
This feature is particularly important for turbocharged or supercharged engines equipped with short intake manifolds.
Price refers to 4 pieces of the product.
