GEMI SX9 Worm Drive Hose Clamp (W2) – Size 12–22 mm / 1 piece
+48 603 775 778
Product Description
GEMI SX9 Worm Drive Hose Clamp (W2) – Size 12–22 mm / 1 piece
Technical Specifications:
-
Clamp range: 12–22 mm
-
Band width: 9 mm
-
Band and housing made of W2 stainless steel – DIN 1.4016
-
Screw made of zinc-plated, Cr(VI)-free steel – DIN 1.1132 / 1.5525
Tightening Torque:
-
Size 12–22: max 3.5 Nm, recommended 3–3.5 Nm
-
Recommended tightening speed: 350 RPM
Product Features:
-
The GEMI SX9 is a proven hose clamp offering exceptionally high sealing performance.
-
Its actual quality significantly exceeds the requirements of DIN 1.1132 / 1.5525.
-
Asymmetrically embossed band teeth and an asymmetrical screw housing prevent clamp distortion in the direction of applied torque.
-
The universal screw head allows for easy installation using a variety of tools.
-
For professional installation, we recommend using a special screwdriver with a flexible shaft to ensure secure assembly even in hard-to-reach areas.
The price is for 1 clamp.
