GEMI SX9 Worm Drive Hose Clamp (W2) – Size 12–22 mm / 1 piece

Product Description

GEMI SX9 Worm Drive Hose Clamp (W2) – Size 12–22 mm / 1 piece

Technical Specifications:

• Clamp range: 12–22 mm

• Band width: 9 mm

• Band and housing made of W2 stainless steel – DIN 1.4016

• Screw made of zinc-plated, Cr(VI)-free steel – DIN 1.1132 / 1.5525

Tightening Torque:

• Size 12–22: max 3.5 Nm, recommended 3–3.5 Nm

• Recommended tightening speed: 350 RPM

Product Features:

• The GEMI SX9 is a proven hose clamp offering exceptionally high sealing performance.

• Its actual quality significantly exceeds the requirements of DIN 1.1132 / 1.5525.

• Asymmetrically embossed band teeth and an asymmetrical screw housing prevent clamp distortion in the direction of applied torque.

• The universal screw head allows for easy installation using a variety of tools.

• For professional installation, we recommend using a special screwdriver with a flexible shaft to ensure secure assembly even in hard-to-reach areas.

The price is for 1 clamp.
