GEMI SX9 Worm Drive Hose Clamp (W2) – Size 8-12 / 1 pc
+48 603 775 778
Product Description
GEMI SX9 Worm Drive Hose Clamp (W2) – Size 8-12 / 1 pc
Technical Specifications:
-
Clamp range: 8–12 mm
-
Band width: 9 mm
-
Band and housing made of W2 stainless steel – DIN 1.4016
-
Screw made of zinc-plated steel, Cr(VI)-free – DIN 1.1132 / 1.5525
Tightening torque:
-
Sizes 8–12: max 2.5 Nm, recommended 2–2.5 Nm
-
Recommended tightening speed: 350 RPM
Features:
-
The GEMI SX9 is a proven hose clamp that ensures exceptionally high sealing performance.
-
The actual quality of these clamps significantly exceeds the DIN 1.1132 / 1.5525 standard requirements.
-
Asymmetrically stamped teeth and screw housing prevent the clamp from twisting in the direction of applied torque.
-
The screw head has a universal design, allowing for easy installation using various tools.
-
For professional installation, a special screwdriver with a flexible shaft is recommended for secure mounting, even in hard-to-reach areas.
The price refers to 1 piece of the clamp.
