Hercules GISM-I3010 Injector – Single Installation for 1 Cylinder

Product Description

Hercules GISM-I3010 Injector – Single Installation for 1 Cylinder

Technical Data:

• Operating temperature: -40°C to +120°C

• Built-in gas inlet filter

• Allowed operating pressure: 0.2 – 4.2 bar

• Maximum operating pressure: 4.5 bar

• Coil resistance: 1.7 Ω

• Inlet diameter: 6 mm

• Outlet diameter: 6 mm

• Supply voltage: DC 6V – 18V

• Opening time: 2.5 ms

• Closing time: 0.8 ms

Application:

Designed for single installation in sequential gas injection systems.

Injector flow rate is regulated using calibration nozzles:

• 1.9 mm nozzle – up to 29 HP per cylinder

• 2.1 mm nozzle – 17 to 27 HP per cylinder

• 2.4 mm nozzle – 24 to 36 HP per cylinder

• Without nozzle – from 33 to 47 HP per cylinder

Price applies to 1 piece.
