Hana Injector Blue H2000 Type A+ 1.3 Ohm H2000 Rail

Product Description

HANA Injector – Model H2001
Color: Blue, Type A+, designed for installation on a rail or distributor.

Technical Specifications

• Flow capacity: 42–60 HP per cylinder

• Coil resistance: 1.3 Ω

• Operating voltage: 12 V DC

• Opening time: 2.36 ms

• Closing time: 1.2 ms

• Maximum working pressure: 4.0 bar

• Recommended working pressure: 1.2 bar

• Inlet port outer diameter: 12 mm

• Outlet port outer diameter: 6 mm

• Connector type: Superseal

• Operating temperature range: –40°C to +120°C

Recommended Injector Types

Depending on engine displacement, four injector variants are available:

• 2,000 cc – 5,400 cc (175 ± 1 l/min) – Blue (Type A+): 40–60 HP per cylinder

• 2,000 cc – 5,400 cc (175 ± 1 l/min) – Green (Type A): 41–50 HP per cylinder

• 1,300 cc – 2,000 cc (154 ± 1 l/min) – Red (Type B): 35–40 HP per cylinder

• 800 cc – 1,200 cc (130 ± 1.5 l/min) – Black (Type C): 27–35 HP per cylinder

Price is for one piece (1 unit).
