HANA H2001 Type Gold (15–50 HP) for Hose Connection (1 piece)
76,00 zł
61,79 zł Excl. VAT
Shopping without registration You do not need to register to place an order
Order by phone+48 603 775 778
Product Description
HANA H2001 Type Gold (15–50 HP) for Hose Connection (1 piece)
Technical Specifications
-
Flow rate: 15–50 HP per cylinder
-
Coil resistance: 1.9 Ohm
-
Voltage: 12 V DC
-
Opening time: 2.36 ms
-
Closing time: 1.2 ms
-
Maximum operating pressure: 4.0 bar
-
Operating pressure: 1.2 bar
-
Inlet port outer diameter: 12 mm
-
Outlet port outer diameter: 6 mm
-
Connector type: Superseal
-
Operating temperature range: –40°C to +120°C
-
GOLD version is calibrated using nozzles (not included)
-
Installation requires a 2-cylinder, 3-cylinder, or 4-cylinder rail
Application Overview – HANA H2001 Injector Types
| Model | Type | Nozzle Type | Resistance | Power per Cylinder (±15%) | 4 Cylinders | 6 Cylinders | 8 Cylinders | Operating Pressure |
|---|---|---|---|---|---|---|---|---|
| Type A+ | Blue | – | 1.3 Ohm | 40 / 50 / 60 HP | 160–240 HP | 240–360 HP | 320–480 HP | 0.8 / 1.0 / 1.2 bar |
| Type A (Gold) | Green | – | 1.9 Ohm | 33 / 42 / 50 HP | 132–200 HP | 198–300 HP | 264–400 HP | |
| Type B | Red | 2.4 mm – One band ` | ` | 1.9 Ohm | 26 / 32 / 39 HP | 104–156 HP | 156–234 HP | 208–312 HP |
| Type C | Black | 2.1 mm – Two bands ` | ` | 1.9 Ohm | 20 / 25 / 30 HP | 80–120 HP | 120–180 HP | |
| Type D | Purple | 1.9 mm – Three bands ` | ` | 1.9 Ohm | 15 / 19 / 24 HP | 60–96 HP |
Price is for 1 injector.
