HANA H2001 Type Gold (15–50 HP) for Rail Connection (1 piece)
+48 603 775 778
Product Description
HANA H2001 Type Gold (15–50 HP) for Rail Connection (1 piece)
Technical Specifications
-
Performance: 15–50 HP per cylinder
-
Coil resistance: 1.9 Ohm
-
Voltage: 12 V DC
-
Opening time: 2.36 ms
-
Closing time: 1.2 ms
-
Maximum operating pressure: 4.0 bar
-
Operating pressure: 1.2 bar
-
Outer diameter of inlet fitting: 12 mm
-
Outer diameter of outlet fittings: 6 mm
-
Connector type: Superseal
-
Operating temperature range: -40°C to 120°C
-
GOLD is calibrated using a nozzle (not included)
-
Requires rail, T-connectors, and elbow fittings for installation
Application Description
HANA H2001 product application details below.
| HANA H2001 | HANA Type | Nozzle Type | Resistance | Power Range (HP) | Operating Pressure |
|---|---|---|---|---|---|
| HP per Cylinder (±15%) (min/-/max) | 4 Cylinder | 6 Cylinder | 8 Cylinder | ||
| Type A+ (Blue) | Type A+ (Blue) | - | 1.3 Ohm | 40 / 50 / 60 HP | 160 ~ 240 HP |
| Type A (GOLD) | Type A (Green) | - | 1.9 Ohm | 33 / 42 / 50 HP | 132 ~ 200 HP |
| Type B (Red) | 2.4 mm, Single Stripe ( | ) | 1.9 Ohm | 26 / 32 / 39 HP | 104 ~ 156 HP |
| Type C (Black) | 2.1 mm, Double Stripes ( | ) | 1.9 Ohm | 20 / 25 / 30 HP | |
| Type D (Purple) | 1.9 mm, Triple Stripes ( | ) | 1.9 Ohm |
Price applies to 1 injector.
